ASHK5-32.768KHZ-LT
XTAL OSC XO 32.7680KHZ CMOS SMDManufacturer: Abracon LLC
Categories: Oscillators
Quality Control: Learn More
Abracon LLC ASHK series XO (Standard) oscillator, part number ASHK5-32-768KHZ-LT. This surface mount component operates at a precise 32.768 kHz frequency with a tight stability of +10ppm, -140ppm. Featuring a 4-SMD, No Lead package (0.157" L x 0.098" W), this oscillator is designed for a 1.5V supply voltage and consumes a maximum of 1µA. The ASHK5-32-768KHZ-LT includes an Enable/Disable function for flexible control. Its compact 0.039" (1.00mm) seated height and 4.00mm x 2.50mm dimensions make it suitable for space-constrained applications. This component is commonly found in consumer electronics, industrial automation, and automotive systems. Packaged on tape and reel (TR) for automated assembly.
Additional Information
Series: ASHKRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.157"" L x 0.098"" W (4.00mm x 2.50mm) |
| Mounting Type | Surface Mount |
| Output | CMOS |
| Function | Enable/Disable |
| Type | XO (Standard) |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | -140ppm, +10ppm |
| Voltage - Supply | 1.5V |
| Ratings | - |
| Current - Supply (Max) | 1µA |
| Height - Seated (Max) | 0.039"" (1.00mm) |
| Absolute Pull Range (APR) | - |
| Frequency | 32.768 kHz |
| Base Resonator | Crystal |
