ATL-1Z100512SR08KT
FIXED IND 80NH 75A 0.125MOHMManufacturer: Abracon LLC
Categories: Fixed Inductors
Quality Control: Learn More
80 nH Unshielded Molded Inductor 75 A 0.125mOhm Nonstandard
Additional Information
Series: ATL-1Z100512SRoHS Status: ROHS3 CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±10% |
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.394"" L x 0.197"" W (10.00mm x 5.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | Molded |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 0.125mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 111A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.472"" (12.00mm) |
| Inductance | 80 nH |
| Current Rating (Amps) | 75 A |
Request a Quote
