ASPIAIG-Q7030-5R6M-T
FIXED IND 5.6UH 7.3A 33.2MOHM SMManufacturer: Abracon LLC
Categories: Fixed Inductors
Quality Control: Learn More
Abracon LLC ASPIAIG-Q7030 series molded power inductor, part number ASPIAIG-Q7030-5R6M-T. This shielded component offers a nominal inductance of 5.6 µH with a ±20% tolerance, tested at 100 kHz. It features a high current rating of 7.3 A and a saturation current (Isat) of 11.5 A, with a maximum DC resistance of 33.2 mOhm. The device is constructed with an alloy powder core and designed for surface mounting with dimensions of 7.80mm L x 7.60mm W and a maximum seated height of 3.10mm. Operating across a temperature range of -55°C to 155°C, this AEC-Q200 qualified inductor is suitable for demanding automotive and industrial applications. Packaging is provided on tape and reel.
Additional Information
Series: ASPIAIG-Q7030RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.307"" L x 0.299"" W (7.80mm x 7.60mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 155°C |
| DC Resistance (DCR) | 33.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Current - Saturation (Isat) | 11.5A |
| Material - Core | Alloy Powder |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.122"" (3.10mm) |
| Inductance | 5.6 µH |
| Current Rating (Amps) | 7.3 A |
