ASPI-0612FS-6R8M-T
FIXED IND 6.8UH 1.35A 215MOHM SMManufacturer: Abracon LLC
Categories: Fixed Inductors
Quality Control: Learn More
Abracon LLC ASPI-0612FS series shielded drum core wirewound inductor, part number ASPI-0612FS-6R8M-T. This surface mount component offers a nominal inductance of 6.8 µH with a ±20% tolerance, tested at 100 kHz. It features a maximum DC resistance of 215 mOhm and a current rating of 1.35 A, with a saturation current of 1.3 A. The inductor is constructed with a ferrite core and measures 6.00mm x 6.00mm with a maximum seated height of 1.20mm. Operating temperature range is -40°C to 105°C. This component is commonly utilized in power supply filtering, DC-DC converters, and various signal processing applications within the automotive and industrial sectors. Supplied on tape and reel.
Additional Information
Series: ASPI-0612FSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Tape & Reel (TR) |
| Package / Case | Nonstandard |
| Size / Dimension | 0.236"" L x 0.236"" W (6.00mm x 6.00mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Drum Core, Wirewound |
| Operating Temperature | -40°C ~ 105°C |
| DC Resistance (DCR) | 215mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Current - Saturation (Isat) | 1.3A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.047"" (1.20mm) |
| Inductance | 6.8 µH |
| Current Rating (Amps) | 1.35 A |
