S-5724HCBH1-M3T1U
MAGNETIC SWITCH LATCH SOT23-3Manufacturer: ABLIC Inc.
Categories: Switches (Solid State)
Quality Control: Learn More
ABLIC Inc. S-5724 series Hall Effect latching magnetic switch, part number S-5724HCBH1-M3T1U, offers a digital push-pull output in a SOT-23-3 package. This device operates with a supply voltage range of 1.6V to 3.5V and features a low supply current of 11µA maximum. The latching function, triggered by south pole magnetic field detection, has a typical trip point of 4mT and a release point of -4mT. Designed for surface mounting, it is supplied on tape and reel. Applications include position sensing in consumer electronics, automotive systems, and industrial controls. The operating temperature range is -40°C to 85°C.
Additional Information
Series: S-5724RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Output Type | Push-Pull |
| Polarization | South Pole |
| Mounting Type | Surface Mount |
| Function | Latch |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 1.6V ~ 3.5V |
| Technology | Hall Effect |
| Sensing Range | 4mT Trip, -4mT Release |
| Current - Output (Max) | 1mA |
| Current - Supply (Max) | 11µA |
| Supplier Device Package | SOT-23-3 |
| Test Condition | 25°C |
