S-1131B30UC-N4PTFG
IC REG LINEAR 3V 300MA SOT89-5Manufacturer: ABLIC Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The ABLIC Inc. S-1131 series linear voltage regulator, part number S-1131B30UC-N4PTFG, provides a fixed 3V positive output with a maximum current capability of 300mA. This LDO regulator features a low quiescent current of 1µA and a supply current of 65µA, making it suitable for power-sensitive applications. The S-1131B30UC-N4PTFG offers robust protection with over-current and an effective enable control. Its high Power Supply Rejection Ratio (PSRR) of 70dB at 1kHz ensures clean power delivery. The device operates within a temperature range of -40°C to 85°C and is housed in a SOT-89-5 package. This component finds application in portable electronics, industrial control systems, and automotive power management. The dropout voltage is a maximum of 0.34V at 100mA, with a maximum input voltage of 6.5V.
Additional Information
Series: S-1131RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: Last Time BuyPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-89-5/6 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 300mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 1 µA |
| Voltage - Input (Max) | 6.5V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-89-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3V |
| Control Features | Enable |
| PSRR | 70dB (1kHz) |
| Voltage Dropout (Max) | 0.34V @ 100mA |
| Protection Features | Over Current |
| Current - Supply (Max) | 65 µA |
