963106-2000-AR-PR
CONN RCPT 6POS 0.1 GOLD SMDManufacturer: 3M
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
The 3M 963 Series 963106-2000-AR-PR is a 6-position receptacle connector designed for surface mounting. Featuring a 0.100" (2.54mm) pitch, this connector offers gold contact finish for mating with a tin contact finish on the post, with a FLASH thickness for mating contacts. The receptacle supports bottom or top entry and is constructed with UL94 V-0 rated materials for insulation color black and an insulation height of 0.295" (7.50mm). It is rated for 2A current and 1000VDC, with an operating temperature range of -25°C to 105°C. The connector is supplied on tape and reel, suitable for pick-and-place assembly. This component finds application in industrial automation and consumer electronics where reliable board-to-board connections are critical.
Additional Information
Series: 963RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Pick and Place |
| Packaging | Tape & Reel (TR) |
| Connector Type | Receptacle, Bottom or Top Entry |
| Voltage Rating | 1000VDC |
| Current Rating (Amps) | 2A |
| Mounting Type | Surface Mount |
| Number of Positions | 6 |
| Style | Board to Board |
| Operating Temperature | -25°C ~ 105°C |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | FLASH |
| Contact Finish - Post | Tin |
| Contact Length - Post | - |
| Insulation Height | 0.295"" (7.50mm) |
| Row Spacing - Mating | - |
| Number of Rows | 1 |
