953230-2000-AR-PR
CONN RCPT 30POS 0.079 GOLD SMDManufacturer: 3M
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
The 3M 953 series 953230-2000-AR-PR is a 30-position receptacle with a 0.079" (2.00mm) pitch. This surface mount connector features gold plated contacts with a flash thickness for mating, designed for robust board-to-board applications. It supports a 1A current rating and a voltage rating of 1000VDC. The receptacle offers bottom or top entry for versatile assembly and is suitable for pick and place operations. With a UL94 V-0 material flammability rating and an operating temperature range of -40°C to 105°C, this component is engineered for reliability in demanding environments. Industries such as consumer electronics and industrial automation commonly utilize connectors with these specifications for their compact footprint and secure mating. The component is supplied on tape and reel.
Additional Information
Series: 953RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Pick and Place |
| Packaging | Tape & Reel (TR) |
| Connector Type | Receptacle, Bottom or Top Entry |
| Voltage Rating | 1000VDC |
| Current Rating (Amps) | 1A |
| Mounting Type | Surface Mount |
| Number of Positions | 30 |
| Style | Board to Board |
| Operating Temperature | -40°C ~ 105°C |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Insulation Color | Black |
| Pitch - Mating | 0.079"" (2.00mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | FLASH |
| Contact Finish - Post | Tin |
| Contact Length - Post | - |
| Insulation Height | 0.169"" (4.30mm) |
| Row Spacing - Mating | 0.079"" (2.00mm) |
| Number of Rows | 2 |
