UHM-S055B3-5AP1-TG30
CONN RECEPT 55POS 2MM PRESS-FITManufacturer: 3M
Categories: Hard Metric, Standard
Quality Control: Learn More
3M UHM Series receptacle connector, part number UHM-S055B3-5AP1-TG30, is a 55-position, 2.00mm pitch female socket connector designed for through-hole, right-angle mounting. This Hard Metric Standard component features a B 11 connector style and utilizes press-fit termination for robust interconnection. The gold contact finish, with a thickness of 30.0µin (0.76µm), ensures reliable conductivity. This receptacle is specifically utilized in CompactPCI applications, commonly found in industrial computing, telecommunications, and data acquisition systems. The connector is supplied in bulk packaging.
Additional Information
Series: UHMRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 55 |
| Pitch | 0.079"" (2.00mm) |
| Number of Rows | 5 |
| Number of Positions Loaded | All |
| Termination | Press-Fit |
| Connector Usage | CompactPCI |
| Connector Style | B 11 |
| Contact Finish Thickness | 30.0µin (0.76µm) |
