HSHM-H176D5-8CP2-TG30
CONN HEADER 176POS 2MM PRESS-FITManufacturer: 3M
Categories: Hard Metric, Standard
Quality Control: Learn More
3M MetPak™ HSHM Series HSHM-H176D5-8CP2-TG30 is a 176-position, 8-row, 2.00mm pitch male pin header connector designed for press-fit termination. This through-hole mounted component features a gold contact finish with a thickness of 30.0µin (0.76µm) for enhanced conductivity and durability. The connector style is D 22, and it is intended for backplane applications. This robust connector is utilized in demanding industries such as telecommunications, data networking, and industrial control systems where high reliability and signal integrity are paramount.
Additional Information
Series: MetPak™ HSHMRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Connector Type | Header, Male Pins |
| Contact Finish | Gold |
| Mounting Type | Through Hole |
| Number of Positions | 176 |
| Pitch | 0.079"" (2.00mm) |
| Number of Rows | 8 |
| Number of Positions Loaded | All |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Connector Style | D 22 |
| Contact Finish Thickness | 30.0µin (0.76µm) |
