CP2-SAB125-1-KR
CONN RECEPT 125POS 2MM PRESS-FITManufacturer: 3M
Categories: Hard Metric, Standard
Quality Control: Learn More
3M MetPak™ CP2 Series CP2-SAB125-1-KR is a 125-position receptacle connector featuring female sockets with a 0.079" (2.00mm) pitch. This right-angle, through-hole mounted component utilizes a press-fit termination for robust interconnection. The connector is designed for CompactPCI applications, offering a hard metric standard configuration. Each of the 125 positions is loaded, arranged in 5 rows. The contact finish is gold with a thickness of 30.0µin (0.76µm), ensuring reliable signal integrity. This connector is suitable for demanding applications in the telecommunications and industrial automation sectors.
Additional Information
Series: MetPak™ CP2RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 125 |
| Pitch | 0.079"" (2.00mm) |
| Number of Rows | 5 |
| Number of Positions Loaded | All |
| Termination | Press-Fit |
| Connector Usage | CompactPCI |
| Connector Style | AB 25 |
| Contact Finish Thickness | 30.0µin (0.76µm) |
