CP2-HB125-GA1-TG30
CONN HEADER 175POS 2MM PRESS-FITManufacturer: 3M
Categories: Hard Metric, Standard
Quality Control: Learn More
3M MetPak™ CP2 series connector, part number CP2-HB125-GA1-TG30, is a 175-position male pin header designed for press-fit termination. This hard metric connector features a 2.00mm pitch and a robust B 25 connector style. The 175 positions include 125 signal contacts and 50 ground contacts, all loaded and utilizing gold plating with a 30.0µin (0.76µm) thickness for enhanced conductivity and durability. Engineered for through-hole mounting, this component is integral to CompactPCI Hot Swap applications, commonly found in telecommunications infrastructure, industrial automation, and high-performance computing systems where reliable, high-density interconnectivity is critical. The bulk packaging facilitates efficient integration into high-volume manufacturing processes.
Additional Information
Series: MetPak™ CP2RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Connector Type | Header, Male Pins |
| Contact Finish | Gold |
| Mounting Type | Through Hole |
| Number of Positions | 175 (125 + 50 Ground) |
| Pitch | 0.079"" (2.00mm) |
| Number of Rows | 5 + 2 |
| Number of Positions Loaded | All |
| Termination | Press-Fit |
| Connector Usage | CompactPCI Hot Swap |
| Connector Style | B 25 |
| Contact Finish Thickness | 30.0µin (0.76µm) |
