82080-6000
CONN RCPT 80POS IDC 30AWG GOLDManufacturer: 3M
Categories: Free Hanging, Panel Mount
Quality Control: Learn More
The 3M 820 series 82080-6000 is an 80-position rectangular receptacle connector designed for reliable ribbon cable termination via Insulation Displacement Connection (IDC). Featuring a gold contact finish with a thickness of 30.0µin (0.76µm), this connector ensures excellent conductivity and corrosion resistance. The 0.050" (1.27mm) pitch and 0.100" (2.54mm) row spacing are optimized for high-density applications. This free-hanging (in-line) mount component is specified for 30 AWG wire gauge and is supplied in bulk packaging. Its design is suited for use in telecommunications, industrial automation, and consumer electronics sectors.
Additional Information
Series: 820RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Feed Through |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Contact Finish | Gold |
| Color | Gray |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 30 AWG |
| Number of Positions | 80 |
| Pitch | 0.050"" (1.27mm) |
| Contact Type | Female Socket |
| Fastening Type | - |
| Row Spacing | 0.100"" (2.54mm) |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Wire Type | Ribbon Cable |
| Cable Termination | IDC |
| Number of Rows | 2 |
Request a Quote
