82036-6000RB
CONN RCPT 36POS IDC 30AWG GOLDManufacturer: 3M
Categories: Free Hanging, Panel Mount
Quality Control: Learn More
3M 820 Series receptacle connector, part number 82036-6000RB, is a 36-position, 2-row, IDC (Insulation Displacement Connector) designed for ribbon cable termination. Featuring gold-plated female socket contacts with a 30.0µin (0.76µm) finish, this connector ensures reliable signal integrity. The 0.050" (1.27mm) pitch and 0.100" (2.54mm) row spacing facilitate dense interconnect solutions. Manufactured for 30 AWG wire gauge, it offers a feed-through feature for in-line, free-hanging applications. This component is commonly utilized in telecommunications, industrial automation, and consumer electronics where high-density interconnects are critical. The connector is supplied in bulk packaging and features a gray housing.
Additional Information
Series: 820RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Feed Through |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Contact Finish | Gold |
| Color | Gray |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 30 AWG |
| Number of Positions | 36 |
| Pitch | 0.050"" (1.27mm) |
| Contact Type | Female Socket |
| Fastening Type | - |
| Row Spacing | 0.100"" (2.54mm) |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Wire Type | Ribbon Cable |
| Cable Termination | IDC |
| Number of Rows | 2 |
