CONN D-SUB RCPT 9POS PNL MNT IDCManufacturer: 3M
Categories: D-Sub Connector Assemblies
Quality Control: Learn More
The 3M 8309-7000 is a 9-position D-Sub receptacle featuring female sockets. This component from the 3M 8300 series is designed for panel mounting with an IDC termination method, suitable for ribbon cable applications. It offers a 1A current rating per contact and boasts a gold contact finish with a thickness of 30.0µin (0.76µm) for robust signal integrity. The connector utilizes a steel shell with tin plating for durability and has a UL94 V-0 material flammability rating. Its shell size is 1 (DE, E) with two rows of contacts. This D-Sub connector finds application in various industries requiring reliable data transmission, including telecommunications, industrial automation, and test and measurement equipment.
Additional Information
Series: 8300RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Current Rating (Amps) | 1A |
| Mounting Type | Panel Mount |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (Unthreaded) |
| Termination | IDC, Ribbon Cable |
| Ingress Protection | - |
| Connector Style | D-Sub |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Material, Finish | Steel, Tin Plated |
| Shell Size, Connector Layout | 1 (DE, E) |
| Backset Spacing | - |
