8250-7005
CONN D-SUB PLUG 50P PNL MNT IDCManufacturer: 3M
Categories: D-Sub Connector Assemblies
Quality Control: Learn More
The 3M 8250-7005 is a 50-position D-Sub plug connector for panel mounting, featuring male pins. This component belongs to the 3M 8250 series and utilizes Insulation Displacement Connection (IDC) termination for ribbon cable. The connector boasts a gold contact finish with a thickness of 30.0µin (0.76µm) and is rated for a 1A current. It includes grounding indents and a steel, nickel-plated shell with a 4-40 flange feature for secure panel mounting. The shell size and layout correspond to the DD, D designation. Material flammability rating is UL94 V-0. This connector is suitable for applications in telecommunications, industrial automation, and test and measurement equipment.
Additional Information
Series: 8250RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Grounding Indents |
| Packaging | Bulk |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Current Rating (Amps) | 1A |
| Mounting Type | Panel Mount |
| Number of Positions | 50 |
| Number of Rows | 3 |
| Contact Type | Signal |
| Flange Feature | Housing/Shell (4-40) |
| Termination | IDC, Ribbon Cable |
| Ingress Protection | - |
| Connector Style | D-Sub |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Material, Finish | Steel, Nickel Plated |
| Shell Size, Connector Layout | 5 (DD, D) |
| Backset Spacing | - |
