STMicroelectronics 3-Axis Digital Accelerometer Solution

: ST Microelectronics 3-Axis Digital Accelerometer Solution products

The STMicroelectronics 3-axis digital accelerometer solution is for smarter, easier-to-use, and energy-efficient portable devices. In ultra-compact packages, this digital accelerometer offers outstanding stability over time and temperature, making it the best solution for the most demanding consumer and industrial applications. The LIS3DSHTR, LIS3DHTR, LIS2HH12TR, LIS2DH12TR, and LIS2DE12TR accelerometers operate in ultra-low-power modes, significantly reducing overall system power consumption and extending battery life. Additionally, they feature smart motion capabilities like sleep-to-wake and return-to-sleep functions, enabling the design of user-friendly and precise user interfaces.

Features

STMicroelectronics 3-axis digital accelerometer solution offers advanced features such as high resolution, power-down, sleep, and ultra-low power operating modes for advanced power saving. With selectable full-scale ranges up to 16g, this solution also includes smart embedded functions such as 4D/6D orientation detection, auto wake-up, and return to sleep. Additional features include:

  • Programmable interrupts and embedded FIFO
  • Embedded state machines for custom motion recognition (LIS3DSH)
  • Digital interfaces IĀ²C/SPI
  • Output data rates from 1 Hz to 5kHz
  • Embedded temperature sensor

Benefits

STMicroelectronics 3-axis digital accelerometer solution offers extremely accurate motion sensing capabilities in small and sleek consumer gadgets. Additional benefits include:

  • Design flexibility
  • Extremely low power consumption maximizes battery life
  • Embedded FIFO for smart data storage and power-saving
  • State machines enable custom motion recognition inside the sensor, further reducing system complexity
  • Temperature detection for advanced thermal drift compensation

Device Summary

STMicroelectronics 3-axis digital accelerometer solution includes the LIS3DSHTR, LIS3DHTR, LIS2HH12TR and LIS2DE12TR.

Accelerometer with Embedded State Machines

The LIS3DSHTR is a high-performance, ultra-low-power, 3-axis linear accelerometer integrated with two embedded finite-state machines. These programmable blocks enable users to create customized motion-detection applications with enhanced flexibility, operating autonomously to reduce the microprocessorā€™s workload by internalizing the programming functionality within the sensor. Each finite-state machine can be independently programmed for motion detection, offering 16 states for data storage. The device can also be configured to generate interrupt signals triggered by user-defined motion patterns

Click here for a detailed STMicroelectronics 3-axis digital accelerometer solution device summary.

Applications

Applications of ST Microelectronics 3-Axis Digital Accelerometer Solution

STMicroelectronics 3-axis digital accelerometer solution is versatile, with applications ranging from activity monitors to industrial machinery.

Consumer Electronics

  • Motion detection in smartphones, tablets and gaming controllers
  • Screen orientation, motion-activated functions, and power saving in mobile devices
  • Enhanced interactive experiences in gaming and VR

Industrial

  • Vibration monitoring and compensation in machinery
  • Tilt monitoring and vibration compensation

Healthcare

  • Activity tracking in medical devices

Wearable Devices

  • Pedometers and activity monitors

Safety Systems

  • Impact recognition and logging
  • Free-fall detection

Automotive

  • Impact recognition and logging and telematics

Product Selector

LIS3DSHTR

  • Package: LGA-16 3 x 3 x 1 mm
  • Packing type: Tape and reel

LIS3DHTR

  • Package: LGA-16 3 x 3 x 1 mm
  • Packing type: Tape and reel

LIS2HH12TR

  • Package: LGA-12 2 x 2 x 1 mm
  • Packing type: Tape and reel

LIS2DH12TR

  • Package: LGA-12 2 x 2 x 1 mm
  • Packing type: Tape and reel

LIS2DE12TR

  • Package: LGA-12 2 x 2 x 1 mm
  • Packing type: Tape and reel

Purchase

Are you looking for an STMicroelectronics 3-axis digital accelerometer solution for smarter, easier-to-use, and energy-efficient portable devices? At Microchip USA, we can offer these advanced accelerometers at the lowest cost and provide supply chain management services to ensure timely delivery and help you keep your projects on schedule. Our team of experts is here to assist you in finding the ideal accelerometer for your next project providing seamless support throughout the process.
