Kintex UltraScale+ is a family of Field-Programmable Gate Arrays (FPGAs) developed by Xilinx (now owned by AMD), a leading provider of programmable logic devices. Kintex UltraScale+ FPGAs are designed to deliver high-performance computing with low power consumption, making them ideal for applications across aerospace, defense, automotive, and communications.
Key Features
The Kintex UltraScale+ family of FPGAs offers several key features that set them apart from other FPGAs on the market.
High-Performance Computing
The Kintex UltraScale+ FPGAs are designed to deliver high-performance computing at speeds up to 1.2 GHz. This makes them ideal for applications that require real-time processing and low latency. The Kintex FPGAs achieve this high performance through a combination of advanced process technology and architectural innovations, including multiple processing engines and dedicated hardware for specific functions.
Low Power Consumption
Kintex FPGAs are designed to operate at low power levels, with power consumption ranging from 15W to 50W, making them ideal for applications where power efficiency is critical, such as in mobile devices and IoT applications. They achieve this low power consumption through a combination of advanced process technology, power management techniques, and architectural innovations, such as power-efficient processing engines and dynamic power management.
Large Capacity
The Kintex UltraScale+ FPGAs come in various sizes, with capacities ranging from 170K to 1.8M logic cells. This makes them suitable for a wide range of applications, from small-scale projects to large-scale industrial applications. They achieve this large capacity through advanced process technology, architectural innovations, and packaging techniques.
Flexible I/O Configurations
Kintex UltraScale+ features flexible I/O configurations, with up to 1,248 I/O pins available. This allows developers to customize their I/O configurations based on their specific requirements. They achieve this flexible I/O configuration through a combination of architectural innovations, packaging techniques, and software tools that simplify the design and implementation of custom I/O configurations.
Architecture
The Kintex UltraScale+ FPGAs architecture is designed to deliver high performance and low power consumption, and offers several key features.
16nm FinFET Technology
The UltraScale+ architecture is built on a 16nm FinFET process, enabling high transistor density and low power consumption. FinFET is a transistor technology that uses a fin-shaped channel to improve control over electron flow. This technology enables higher transistor density, greater processing power, and improved power efficiency.
Heterogeneous 3D System Integration
The architecture features a heterogeneous 3D system integration, allowing multiple technologies to be integrated on a single chip. This results in higher performance and lower power consumption. Heterogeneous 3D system integration enables the integration of different processing engines, memory technologies, and I/O interfaces on a single chip. This enables more efficient communication and data transfer among components, resulting in faster, more power-efficient processing.
UltraRAM
The UltraScale+ architecture features UltraRAM, a new type of memory technology developed by Xilinx. UltraRAM offers high-density, high-performance memory that is optimized for FPGA applications. It offers up to 432 MB of memory and a bandwidth of up to 500 GB/s. UltraRAM is optimized for high-bandwidth applications, such as video processing and data center applications.
High-Bandwidth Memory
The UltraScale+ architecture also features High-Bandwidth Memory (HBM), a new memory technology that offers high bandwidth and low power consumption. HBM is designed to work with other memory technologies, such as DDR4, to provide a high-performance memory subsystem. HBM offers up to 8GB of memory with a bandwidth of up to 512 GB/s.
Multi-Processing Engines
The Kintex architecture features multiple processing engines, including Arm Cortex-A53 processors, programmable logic, and DSP engines. These processing engines work together to provide high-performance computing with low power consumption. The ARM Cortex-A53 processors are based on a 64-bit architecture and offer high-performance processing. The programmable logic and DSP engines also provide flexible processing capabilities that can be customized based on the application’s specific requirements.
Industrial
Kintex UltraScale+ FPGAs are also well-suited for industrial applications, where high reliability, ruggedness, and low power consumption are critical factors. These FPGAs can be used in control systems, motor drives, robotics, and power generation and distribution systems. In industrial applications, Kintex UltraScale+ FPGAs can provide high-speed processing and high-bandwidth communication for real-time control and monitoring, while offering flexibility to adapt to changing requirements and conditions. Additionally, these FPGAs can operate in harsh environments, withstanding extreme temperatures, shock, vibration, and electromagnetic interference, making them ideal for industrial applications.
Capabilities of Kintex UltraScale+ FPGAs
Kintex UltraScale+ FPGAs feature capabilities and specifications that make them a great option for a wide range of high-performance applications.
- 16nm FinFET Technology - Advanced process node delivering improved speed and power efficiency.
- Up to 1.2 Million Logic Cells - Enables large and complex FPGA designs.
- Multiple Processing Engines - Integrates Arm Cortex-A53 processors, programmable logic, and DSP engines for flexible compute architectures.
- Up to 5,520 DSP Slices - Ideal for high-performance signal processing tasks.
- Up to 56Mb of BRAM (Block RAM) - Efficient for intermediate data storage.
- Up to 432Mb of UltraRAM - Enhances capacity for larger memory-intensive tasks.
- Up to 8GB of High-Bandwidth Memory (HBM) - Offers significant bandwidth for data-intensive workloads.
- Up to 4,272 User I/Os - Facilitates integration with complex systems.
- Support for PCIe Gen3 and Gen4 - Enables high-throughput communication interfaces.
- High-Speed Transceivers - Capable of data rates up to 32.75 Gbps for high-performance connectivity.
- Low-Power Operation - Features dynamic power reduction and advanced clock gating for improved energy efficiency.
- Support for Multiple Power Domains and Voltage Levels - Enhances control and flexibility in power-sensitive designs.
- AES-256 Encryption
- Secure Boot - These features offer enhanced protection against unauthorized access and maintain data integrity.
- Vivado Design Suite - Comprehensive toolchain for hardware design.
- Vitis Unified Software Platform - Enables software development and system-level integration.
These combined capabilities position Kintex UltraScale+ FPGAs as a highly versatile and powerful solution for applications spanning aerospace, defense, industrial, and data center environments.
Applications of Kintex UltraScale+ FPGAs
Kintex UltraScale+ FPGAs are purpose-built for a wide array of advanced applications that demand high performance, energy efficiency, and integration flexibility.
- Radar and imaging systems
- Electronic warfare
- Avionics systems
Kintex's high performance and low power profile make it well-suited for environments where efficiency and reliability are paramount.
- Advanced Driver Assistance Systems (ADAS)
- Infotainment platforms
- Vehicle-to-vehicle communication systems
Kintex's ability to deliver real-time processing with minimal power consumption supports both safety and user experience.
- Wireless base stations
- Optical networking equipment
- High-speed switches
Kintex offers the performance and efficiency needed to meet modern networking demands.
- Acceleration and co-processing tasks (AI and machine learning)
- High-speed networking
- Storage optimization
Kintex helps improve throughput and reduce latency while maintaining energy efficiency.
Kintex UltraScale+: A Scalable FPGA Platform for Demanding Applications
Kintex UltraScale+ FPGAs are a powerful and versatile solution for many applications, offering high-performance computing with low power consumption, large capacity, and flexible I/O configurations. They are based on the UltraScale+ architecture, which offers several key features, including 16nm FinFET technology, heterogeneous 3D system integration, UltraRAM, High-Bandwidth Memory, and multiple processing engines. With their advanced capabilities and wide range of applications, Kintex UltraScale+ FPGAs play an essential role in the future of computing and technology.
Looking to source Kintex UltraScale+ FPGAs or other electronic components? Explore our FPGA inventory or request a quote below.
