SA636DK/01,112
IC MIXER 500MHZ UP CONVRT 20SSOPManufacturer: NXP USA Inc.
Categories: RF Mixers
Quality Control: Learn More
NXP USA Inc. SA636DK-01-112 is a single-balanced mixer IC from the SA636 series, designed for RF applications. This upconverter features a 500MHz intermediate frequency (IF) and is suitable for cellular, ASK, DECT, FSK, UHF, and VHF communication systems. The device operates with a supply voltage range of 2.7V to 5.5V and draws a typical current of 6.5mA. It offers a conversion gain of 11dB and a noise figure of 12dB. The mixer is housed in a 20-SSOP package, facilitating surface mounting for efficient board assembly. Its robust performance characteristics make it a valuable component in wireless infrastructure and consumer electronics.
Additional Information
Series: SA636RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 20-LSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 500MHz |
| RF Type | Cellular, ASK, DECT, FSK, UHF, VHF |
| Voltage - Supply | 2.7V ~ 5.5V |
| Gain | 11dB |
| Current - Supply | 6.5mA |
| Secondary Attributes | Up Converter |
| Noise Figure | 12dB |
| Number of Mixers | 1 |
| Supplier Device Package | 20-SSOP |
Request a Quote
